LED NeonPRO921 Custom flex stripe Twist+Bend B16H16 24V DC, 10W, IP67, 2100K 140 LED/m, incl. clips
Article is located in the inlet, please contact the internal sales team
Article number
116175
| Article number | 116175 |
|---|---|
| Product description | LED NeonPRO921 Custom flex stripe Twist+Bend B16H16 24V DC, 10W, IP67, 2100K 140 LED/m, incl. clips |
| GTIN - EAN | 9009377155604 |
| Features |        |
| Special features | Separation point: 50mm with 7 SMD each | Pitch (light point center-center): 7,14mm | max. flex stripe length per infeed: 5m | length tolerance + thermal expansion: 1% | no cooling profile required | without adhesive tape! | silicone encapsulation | Special feature: 30cm 2-pole sheathed cable one-sided, white, connection at the front, open stranded wire | Note: end caps flush in width and height, vertically and horizontally bendable (bending radius min. 60mm) | Flame retardant and flame resistant (IEC 60695-11-5), IK08 (IEC 62262), salt spray resistant (IEC 60068-2-11:2021), UV resistant (ASTM G154-2016) |
| Nominal voltage | 24 V DC |
| Rated power | 10 W/m |
| Active power | 10 W/m |
| Luminous flux in lumen | 430 lm/m |
| RGB light source | No |
| Color temperature | 2100K |
| CRI Ra | 90 |
| Cooling mass g/m | 0.00 g/m |
| Beam angle | 120° |
| Pitch SMD (mm) | 7.14 |
| Max. length per feed (m) | 5,0 |
| Type de ruban adhésif | ohne Klebeband |
| Protection class | IP67 |
| Outdoor | Y |
| Permissible ambient temp. | -20°C - 40°C |
| Housing material | Silicone |
| Length in mm | 5000,0 |
| Width in mm | 16,0 |
| Height in mm | 16,0 |
| Lifetime L70|B10 | 38000 |
| Guarantee in years | 3 |
| Excess lengths | N |
