LED CRI930 MiniAMP flex stripe 12V DC, 7W, IP20, 3000K, 500cm, cable both sides + maleAMP, 120 LED/m
In stock
Article number
115749
| Article number | 115749 |
|---|---|
| Product description | LED CRI930 MiniAMP flex stripe 12V DC, 7W, IP20, 3000K, 500cm, cable both sides + maleAMP, 120 LED/m |
| GTIN - EAN | 9009377147388 |
| Features |      |
| Special features | Separation point: 8,33mm with 1 SMD each | Pitch (light point center-center): 8,33mm | 1 unit (roll) = 5m | max. flex stripe length per infeed: 5m | length tolerance + thermal expansion: 1% | required cooling mass min. 45 gr/m | Incl. 3M 300LSE adhesive tape | Clean and degrease surface before application! Do not remove again! | The connectors of the group fit: K2-25 | Connection cable with maleAMP on both sides, wire cross-section 0,5mm² |
| Nominal voltage | 12 V DC |
| Rated power | 7 W/m |
| Active power | 7 W/m |
| Luminous flux in lumen | 650 lm/m |
| RGB light source | No |
| Color temperature | 3000K |
| CRI Ra | 90 |
| Cooling mass g/m | 45.00 g/m |
| Beam angle | 120° |
| Pitch SMD (mm) | 8.33 |
| Max. length per feed (m) | 5,0 |
| Type de ruban adhésif | 3M 300LSE |
| Protection class | IP20 |
| Permissible ambient temp. | -20°C - 40°C |
| Length in mm | 5000,0 |
| Width in mm | 5,0 |
| Height in mm | 2,0 |
| Lifetime L70|B10 | 52000 |
| Guarantee in years | 2 |
| Excess lengths | N |
