LED CRI Food flex stripe meat, 24V DC, 14,4W, IP20, 5m roll, 160 LED/m
In stock
Article number
116806
| Article number | 116806 |
|---|---|
| Product description | LED CRI Food flex stripe meat, 24V DC, 14,4W, IP20, 5m roll, 160 LED/m |
| GTIN - EAN | 9009377167294 |
| Features |        |
| Special features | Separation point: 50mm with 8 SMD each | Pitch (light point center-center): 6mm | 1 unit (roll) = 5m | max. flex stripe length per infeed: 5m | length tolerance + thermal expansion: 1% | required cooling mass min. 75 gr/m | incl. 3M 300LSE adhesive tape | Clean and degrease surface before application! Do not remove again! | Silicone encapsulation | Special feature: connection cable on one side |
| Nominal voltage | 24 V DC |
| Rated power | 14,4 W/m |
| Active power | 12,5 W/m |
| Luminous flux in lumen | 1250 lm/m |
| RGB light source | No |
| Color temperature | 1939K |
| CRI Ra | 82 |
| Cooling mass g/m | 75.00 g/m |
| Beam angle | 120° |
| Pitch SMD (mm) | 6.00 |
| Max. length per feed (m) | 5,0 |
| Type de ruban adhésif | 3M 300LSE |
| Protection class | IP20 |
| Outdoor | Y |
| Permissible ambient temp. | -20°C - 45°C |
| Housing material | Copper |
| Length in mm | 5000,0 |
| Width in mm | 10,0 |
| Height in mm | 1,0 |
| Lifetime L70|B10 | 38000 |
| Guarantee in years | 2 |
| Excess lengths | N |
